SC/APC to SC/APC G.652.D Simplex Patch Cord – 1m to 5m

A reliable SC/APC to SC/APC Single-Mode fiber optic patch cord using one G.652.D fiber core. Available in 1m, 2m, 3m, and 5m lengths for FTTH, network, internet, and telecommunications installations in Lebanon.

Choose the required cable length directly from the product options.

3. Top 5 Benefits

1. SC/APC connectors on both ends
   Ready for equipment and adapters that require SC/APC connections.
2. G.652.D Single-Mode fiber
   Suitable for compatible Single-Mode optical networks and communication systems.
3. Simplex one-core construction
   Provides one optical path for straightforward point-to-point fiber connections.
4. Four practical length options
   Available in 1m, 2m, 3m, and 5m to suit different equipment layouts.
5. Useful for FTTH and network installations
   Suitable for connecting compatible fiber devices, distribution boxes, patch panels, and subscriber equipment.

4. How to Use

1. Select the required length: 1m, 2m, 3m, or 5m.
2. Confirm that both devices or adapters require SC/APC connectors.
3. Switch off or isolate active optical equipment when required by the installation procedure.
4. Remove the protective dust caps without touching the connector tips.
5. Clean and inspect both fiber connectors using proper fiber-cleaning equipment.
6. Insert each SC/APC connector into the compatible port until securely seated.
7. Route the cable without sharp bends, crushing, excessive tension, or twisting.
8. Test the completed optical link using suitable fiber-testing equipment.

Safety warning: Never look directly into a fiber connector, adapter, or active optical port.

5. Full Product Description

SC/APC Fiber Patch Cord for Single-Mode Networks

The SC/APC to SC/APC G.652.D Simplex Fiber Optic Patch Cord provides a ready-to-use optical connection between two compatible SC/APC ports.

It contains one Single-Mode G.652.D fiber core and is available in four useful lengths, allowing installers to choose an option that suits the distance between equipment without leaving excessive cable.

Confirmed Product Specifications

• Product type: Fiber optic patch cord
• Connector A: SC/APC
• Connector B: SC/APC
• Fiber standard: G.652.D
• Fiber type: Single-Mode
• Core count: 1 core
• Configuration: Simplex
• Available lengths: 1m, 2m, 3m, and 5m

Cable diameter, jacket material, jacket color, insertion loss, return loss, operating temperature, and included test report should be confirmed from the supplied product specifications when required for a technical project.

Why SC/APC?

SC/APC connectors use an angled physical-contact end face and are commonly identified by their green connector body. They must be connected only to compatible SC/APC ports or adapters.

SC/APC and SC/UPC connectors should not be directly mated. Mixing the two polish types can lead to poor optical performance and may damage the connector end faces.

Available Length Options

Select the appropriate variation on the product page:

• 1 meter: Suitable for nearby devices, compact cabinets, and short internal links.
• 2 meters: Provides additional reach inside network cabinets and installation areas.
• 3 meters: Useful when equipment is positioned farther apart.
• 5 meters: Suitable for longer internal routes where extra cable length is required.

Choose the shortest practical length that allows proper routing without pulling or placing stress on the connectors.

Suitable Applications

This fiber patch cord can be used with compatible equipment in:

• FTTH installations
• Fiber internet networks
• Optical distribution boxes
• Fiber patch panels
• Telecommunications systems
• Subscriber connections
• Network cabinets
• Optical receivers
• Compatible ONT and ONU installations
• Fiber testing and maintenance setups

For Technicians and Network Installers

The cable is suitable for:

• Fiber optic technicians
• Internet service providers
• Network installers
• Telecommunications contractors
• IT departments
• Building network projects
• Maintenance teams
• Home and office fiber installations

Installation and Handling

Fiber optic patch cords require careful handling. Avoid pulling the cable by its connectors, closing doors or covers over it, exposing it to sharp edges, or bending it tightly.

Keep the protective caps installed whenever the patch cord is disconnected. Even small amounts of dust can affect an optical connection, so both connector ends should be inspected and cleaned before installation.

Important Compatibility Note

This is an SC/APC-to-SC/APC patch cord. Before ordering, confirm that both connection points use SC/APC ports and that G.652.D Single-Mode fiber is suitable for your network.

This listing includes length options of 1m, 2m, 3m, and 5m on the same product page.
